Measures the energy a particle loses as it passes through the detector

They are designed to absorb most of the particles coming from a collision, forcing them to deposit all of their energy and stop within the detector. ATLAS calorimeters consist of layers of an “absorbing” high-density material that stops incoming particles, interleaved with layers of an “active” medium that measures their energy.

Electromagnetic calorimeters measure the energy of electrons and photons as they interact with matter. Hadronic calorimeters sample the energy of hadrons (particles that contain quarks, such as protons and neutrons) as they interact with atomic nuclei. Calorimeters can stop most known particles except muons and neutrinos.

The components of the ATLAS calorimetry system are: the Liquid Argon (LAr) Calorimeter and the Tile Hadronic Calorimeter.

Liquid Argon Calorimeter

The Liquid Argon (LAr) Calorimeter surrounds the ATLAS Inner Detector and measures the energy of electrons, photons and hadrons. It features layers of metal (either tungsten, copper or lead) that absorb incoming particles, converting them into a “shower” of new, lower energy particles. These particles ionise liquid argon sandwiched between the layers, producing an electric current that is measured. By combining all of the detected currents, physicists can determine the energy of the original particle that hit the detector.

The central region of the calorimeter is specially designed to identify electrons and photons. It features a characteristic accordion structure, with a honeycomb pattern, to ensure that no particle escapes unchallenged.

To keep the argon in liquid form, the calorimeter is kept at -184°C. Specially-designed, vacuum-sealed cylinders of cables bring the electronic signals from the cold liquid argon to the warm area where the readout electronics are located.

Tile Hadronic Calorimeter

The Tile Calorimeter surrounds the LAr calorimeter and measures the energy of hadronic particles, which do not deposit all of their energy in the LAr Calorimeter. It is made of layers of steel and plastic scintillating tiles. As particles hit the layers of steel, they generate a shower of new particles. The plastic scintillators in turn produce photons, which are converted into an electric current whose intensity is proportional to the original particle’s energy.

The Tile Calorimeter is made up of about 420,000 plastic scintillator tiles working in sync. It is the heaviest part of the ATLAS experiment, weighing almost 2900 tonnes!

Combining two major ATLAS inner detector components — The semiconductor tracker is inserted into the transition radiation tracker for the ATLAS experiment at the LHC. These make up two of the three major components of the inner detector. They will work together to measure the trajectories produced in the proton-proton collisions at the centre of the detector when the LHC is switched on in 2008. (Image: CERN)

It is the first part of ATLAS to see the decay products of the collisions

It is very compact and highly sensitive. It consists of three different systems of sensors all immersed in a magnetic field parallel to the beam axis. The Inner Detector measures the direction, momentum, and charge of electrically-charged particles produced in each proton-proton collision.

The main components of the Inner Detector are: Pixel Detector, Semiconductor Tracker (SCT), and Transition Radiation Tracker (TRT).

Pixel Detector

Located just 3.3 cm from the LHC beam line, the Pixel Detector is the first point of detection in the ATLAS experiment. It is made up of four layers of silicon pixels, with each pixel smaller than a grain of sand. As charged particles burst out from the collision point, they leave behind small energy deposits in the Pixel Detector. These signals are measured with a precision of almost 10 μm to determine the origin and momentum of the particle. The Pixel Detector is incredibly compact, with over 92 million pixels and almost 2000 detector elements.

92 million pixels (92 million electronic channels).
Silicon area approx. 1.9m². 15 kW power consumption
Pixel size 50 x 400μm² for the external layers and 50 x 250 μm²for the innermost layer (IBL)
4-barrel layers with 1736 sensor modules
3 disks in each end-cap with 288 modules

Semiconductor Tracker

The Semiconductor Tracker surrounds the Pixel Detector and is used to detect and reconstruct the tracks of charged particles produced during collisions. It consists of over 4,000 modules of 6 million “micro-strips” of silicon sensors. Its layout is optimised such that each particle crosses at least four layers of silicon. This allows scientists to measure particle tracks with a precision of up to 25 μm - that’s less than half the width of a human hair!

4,088 two-sided modules and over 6 million implanted readout strips (6 million channels)
60m² of silicon distributed over 4 cylindrical barrel layers and 18 planar endcap discs
Readout strips every 80μm on the silicon

Transition Radiation Tracker

The third and final layer of the Inner Detector is the Transition Radiation Tracker (TRT). Unlike its neighbouring sub-detectors, the TRT is made up of 300,000 thin-walled drift tubes (or “straws”). Each straw is just 4 mm in diameter, with a 30 μm gold-plated tungsten wire in its centre. The straws are filled with a gas mixture. As charged particles cross through the straws, they ionise the gas to create a detectable electric signal. This is used to reconstruct their tracks and, owing to the so-called transition radiation, provides information on the particle type that flew through the detector, i.e. if it is an electron or pion.

350,000 read-out channels
Volume 12m³
Straw tubes with 4mm diameter, with centred 0.03mm diameter gold-plated tungsten wire
50,000 straws in Barrel, each straw 144 cm long.
250,000 straws in both endcaps, each straw 39 cm long
Precision measurement of 0.17 mm (particle track to wire)

The first ATLAS inner detector end-cap after complete insertion within the Liquid Argon Cryostat.

The installation of the ATLAS inner detector end-cap C.

Inner — An ATLAS inner detector end-cap is placed in its cryostat. The instrumentation housed inside the inner end-cap must be kept cool to avoid thermal noise. This cooling is achieved on ATLAS by placing the end-cap inside a liquid argon cryostat. The end-cap measures particles that are produced close to the direction of the beam pipe and would otherwise be missed.

This colorful 3D animation is an excerpt from the film "ATLAS-Episode II, The Particles Strike Back." Shot with a bug's eye view of the inside of the detector. The viewer is taken on a tour of the inner workings of the transitional radiation tracker within the ATLAS detector. Subjects covered include what the tracker is used to measure, its structure, what happens when particles pass through the tracker, how it distinguishes between different types of particles within it. (Video: CERN)

The largest volume detector ever constructed for a particle collider

ATLAS has the dimensions of a cylinder, 46m long, 25m in diameter, and sits in a cavern 100m below ground. The ATLAS detector weighs 7,000 tonnes, similar to the weight of the Eiffel Tower.

The detector itself is a many-layered instrument designed to detect some of the tiniest yet most energetic particles ever created on earth. It consists of six different detecting subsystems wrapped concentrically in layers around the collision point to record the trajectory, momentum, and energy of particles, allowing them to be individually identified and measured. A huge magnet system bends the paths of the charged particles so that their momenta can be measured as precisely as possible.

Beams of particles travelling at energies up to seven trillion electron-volts, or speeds up to 99.999999% that of light, from the LHC collide at the centre of the ATLAS detector producing collision debris in the form of new particles which fly out in all directions. Over a billion particle interactions take place in the ATLAS detector every second, a data rate equivalent to 20 simultaneous telephone conversations held by every person on the earth. Only one in a million collisions are flagged as potentially interesting and recorded for further study. The detector tracks and identifies particles to investigate a wide range of physics, from the study of the Higgs boson and top quark to the search for extra dimensions and particles that could make up dark matter.
